SB12CACS25-8 4" mid/woofer, 25mm VC

Name: SB12CACS25-8 4" mid/woofer, 25mm VC
Brand: SB Acoustics
SKU: 060-2391
Price: 89.48 EUR
Availability: InStock

SB Acoustics

Details

Shipping within (if available from supplier)

6. Dec.

Manufacturer

SB Acoustics

Guarantee

1 év

Further data

Orderable

70.45 € excl. VAT

Details

Nominal Impedance 8 Ω
DC resistance, Re 6.4 Ω
Voice coil inductance, Le 0.34 mH
Effective piston area, Sd 50 cm2
Voice coil diameter 25.4 mm
Voice coil height 15 mm
Air gap height 5 mm
Linear coil travel (p-p) 10 mm
Magnetic flux density 1.07 T
Magnet weight 0.40 kg
Net weight 0.92 kg
Free air resonance, Fs 51 Hz
Sensitivity (2.83 V / 1 m) 85.5 dB
Mechanical Q-factor, Qms 4.85
Electrical Q-factor, Qes 0.4
Total Q-factor, Qts 0.37
Moving mass incl. air, Mms 5.3 g
Force factor, Bl 5.2 Tm
Equivalent volume, VAS 6.5 liters
Compliance, Cms 1.84 mm/N
Mechanical loss, Rms 0.35 kg/s
Rated power handling* 30 W

Info

Net weight (kg)

0.92

Impedance, Z

Chassis diameter

4" (10-12 cm)

Article No.

060-2391

Weight

920 g/db
