The GRS 1TD2-8 designer dome tweeter is an economical replacement for dome tweeters in classic speakers. Its stylized faceplate also makes it a great-looking addition to new builds.
Highlights
- Fabric dome with 1" voice coil
- Round injection-molded faceplate
- Smooth, detailed sound quality
- Great-looking replacement for classic dome tweeters
Product details
GRS 1TD2-8 1" Designer Dome Tweeter 8 Ohm
When you need an economical replacement dome tweeter, but you want to preserve or create an elegant look, make the GRS 1TD2-8 your choice. Its European-styled faceplate makes it the perfect replacement for more expensive dome tweeters, but it’s also great for new designs.
The round 4" faceplate is perfectly sized to fit existing tweeter cutouts, and the shape of the faceplate is curved to reduce edge diffraction for smooth frequency response and great detail. The large ferrite motor provides dynamic output, while the 1" voice coil handles plenty of power. The 8-ohm impedance allows it to work great with most existing crossovers.
Article number1TD2-8
EAN0848864016399
Tweeter TypeReplacement tweeter
Tweeter SeriesSoft dome
Cone / Dome Diameter25 mm | 1"
Power Handling (RMS)50 Watts
Impedance (Z)8 Ω
Sensitivity (SPL at 1m / 2.83V)90 dB
Frequency Response2,100 to 20,000 Hz
Resonant Frequency (Fs)1050 Hz
DC Resistance (Re)7.48 ohms
Voice Coil Inductance (Le)0.11 mH
Mechanical Q (Qms)5.94
Electromagnetic Q (Qes)1.91
Total Q (Qts)1.45
Overall Outside Diameter4.06"
Cutout Diameter2.875"
Depth1.25"
