The GRS A25-2T is a 2-inch dome tweeter that is designed as a replacement for the tweeters used in the Dynaco A25 speakers. It is a high-quality tweeter that will provide clear and accurate sound reproduction. The tweeter has a frequency response of 1,500Hz to 16,000Hz, a sensitivity of 92.8dB 2.83V/1m, and an impedance of 6Ω. The tweeter is made with a fabric dome and has a neodymium magnet.
Highlights
- 2-inch fabric dome
- Neodymium magnet
- Frequency response of 1,500Hz to 16,000Hz
- Sensitivity of 92.8dB 2.83V/1m
- Impedance of 6Ω
- Fully compatible with the original Dynaco crossover network
- Dimensionally accurate design for minimal modification for installation
Product details
GRS A25-2T Dome Tweeter
The GRS A25-2T is a meticulously crafted replacement tweeter for the Dynaco A25. It has identical dome material with an updated motor for improved transient response and accurate music reproduction. The tweeter is fully compatible with the original Dynaco crossover network and requires minimal modification for installation.
Article numberA25-2T
EAN0848864072524
Tweeter TypeReplacement 2" tweeter for the Dynaco A25
Tweeter SeriesReplacements
Cone / Dome Diameter39 mm
Power Handling (RMS)30 Watt
Impedance (Z)6 Ω
Sensitivity (SPL at 1m / 2.83V)87 dB
Frequency Response1500 - 16.000 Hz
Resonant Frequency (Fs)730 Hz
DC Resistance (Re)5.4 Ω
Voice Coil Inductance (Le)0.08 mH
Overall Outside Diameter100 mm
Cutout Diameter65.2 mm
