K-33-4 Replacement 15" Woofer for Klipsch Speakers
K-33-4 Replacement 15" Woofer for Klipsch Speakers
118.90 € excl. VAT

K-33-4 Replacement 15" Woofer for Klipsch Speakers

K-33-4 Replacement 15" Woofer for Klipsch Speakers
K-33-4 Replacement 15" Woofer for Klipsch Speakers
K-33-4 Replacement 15" Woofer for Klipsch Speakers
Shipping within (if available from supplier)
4-5 working days
Manufacturer
GRS
Orderable
118.90 € excl. VAT
Details

The GRS K33 is a 1:1 drop-in replacement for the Klipsch K-33 woofer designed to bring your old Klipsch heritage cabinets back to life! With the same suspension and cone characteristics as the original K-33, this driver performs and will retain the same crossover point, tone, and quality when used with the Klipsch crossover networks in a variety of cabinets.



Highlights

  • Drop-in 4 Ohm replacement woofer for the popular Klipsch K33
  • Fits popular Klipsch Heritage Cabinets: Klipschorn, Belle Klipsch, Cornwall, Lascala
  • Perfect visual match for restored Klipsch cabinets
  • Triple-roll surround and paper cone provide a perfect tonal match
  • Replacement for K-43-E, K-33-B, K-33-J, K-33-K and more



Product details

GRS K-33-4 Replacement 15" Woofer for Klipsch Speakers



The GRS K-33 was designed to have the same performance in free-air as the original in order to have the same performance in-cabinet for worry-free replacement.



The engineers at GRS understand that while performance is important when selecting replacement drivers for a restoration project, aesthetic is close behind in what dictates an appropriate replacement. Using the same materials and colors for paper cone, dustcap, and triple-roll surround, down to the design of the stamped frame, GRS guarantees mis-matched components won't get in the way of enjoying your favorite Klipsch heritage cabinets.



DIY-ers who do not own any of the classic cabinets will appreciate the high-sensitivity and subdued midrange for easy crossover and cabinet design.



Article numberK-33-4
EAN0848864070759
Woofer TypeSubwoofer
Nominal Diameter15"
Power Handling (RMS)200 Watts
Power Handling (max)400 Watts
Impedance (Z)4Ω
Sensitivity (SPL at 1m / 2.83V)97 dB
Frequency Response33-5500Hz
Voice Coil Diameter2"
Magnet Weight59oz.
DC Resistance (Re)3.52Ω
Voice Coil Inductance (Le)1.129mH
Resonant Frequency (Fs)32.2 Hz
Mechanical Q (Qms)12.61
Electromagnetic Q (Qes)0.5458
Total Q (Qts)0.52
Diaphragm Mass Inc. Airload (Mms)91.55g
Mechanical Compliance of Suspension (Cms)0.267mm/N
Surface Area of Cone (Sd)855.3cm²
BL Product (BL)10.93T·m
Compliance Equivalent Volume (Vas)9.68ft³
Maximum Linear Excursion (Xmax)8.25 mm
Cone / Diaphragm MaterialPaper
Surround MaterialPaper
Voice Coil Wire MaterialCopper
Voice Coil FormerAluminum
Basket / Frame MaterialSteel
Magnet MaterialFerrite
Overall Outside Diameter15.11"
Overall Depth5.82"
Baffle Cutout Diameter13.85"
Bolt Circle Diameter14.65
# Mounting Holes8
