Shipping within (if available from supplier)

3-6 weeks

Manufacturer

Sica

Further data

Orderable

Details

General Specifications

Nominal Diameter	269 mm / 10 in
Nominal Impedance	8 Ω
Rated Power AES	300 W
Continuos Program Power	600 W
Sensitivity @ 1W/1m	96.3 dB
Voice Coil Diameter	65 mm (2.5")
Voice Coil Winding Depth	12 mm
Magnetic Gap Depth	8 mm
Flux Density	1.17 T
Magnet Weight	1430 g
Net Weight	4.9 Kg

Constructive Characteristics

Magnet Type	Ferrite
Basket Material	Aluminium Die-Cast
Voice Coil Winding Material	Aluminium
Voice Coil Former Material	Fiberglass
Cone Material	Paper
Cone Treatment	Surface Waterproof Treatment
Surround Material	Treated Cloth
Dust Dome Material	Solid Paper

Mounting Information

Overall Diameter	268 mm
Baffle Cutout Diameter	232 mm
Mounting Holes	8 holes 6×9 on Ø247 mm
Total Depth	119.5 mm

Thiele/Small Parameters

Re	5.5 Ω
Qms	4.23
Qts	0.37
Cms	233 µm/N
Vas	39.7 l
X max	+/- 4.0 mm
N	1.76 %
Fs	57.0 Hz
Qes	0.40
Mms	33.5 g
Bxl	12.80 Tm
Sd	346.4 cm²
X var	+/- 7.0 mm
Le (1KHz)	0.46 mH

Info

Impedance, Z

8

Chassis diameter

10”

Article No.

SIC-Z005710C

Weight

4.9 kg/db
