SICA 12 PFS 3 Woofer

177.57 € excl. VAT

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

SICA 12 PFS 3 Woofer

Manufacturer

Sica

Further data

In stock

177.57 € excl. VAT

Details

General Specifications

Nominal Diameter	321 mm / 12 in
Nominal Impedance	8 Ω
Rated Power AES	500 W
Continuos Program Power	1000 W
Sensitivity @ 1W/1m	93.6 dB
Voice Coil Diameter	75 mm (3")
Voice Coil Winding Depth	24 mm
Magnetic Gap Depth	10 mm
Flux Density	1.04 T
Magnet Weight	1790 g
Net Weight	6.7 Kg

Constructive Characteristics

Magnet Type	Ferrite
Basket Material	Aluminium Die-Cast
Voice Coil Winding Material	Copper
Voice Coil Former Material	Fiberglass
Cone Material	Paper
Cone Treatment	Total Waterproof Treatment
Surround Material	Treated Cloth
Dust Dome Material	Solid Paper

Mounting Information

Overall Diameter	320 mm
Baffle Cutout Diameter	284 mm
Mounting Holes	8 holes 6×9 on Ø301 mm
Total Depth	141.3 mm

Thiele/Small Parameters

Re	5.1 Ω
Qms	5.35
Qts	0.47
Cms	146 µm/N
Vas	58.5 l
X max	+/- 7.0 mm
N	0.86 %
Fs	43.0 Hz
Qes	0.51
Mms	93.7 g
Bxl	15.89 Tm
Sd	530.9 cm²
X var	+/- 10.0 mm
Le (1KHz)	1.07 mH

Info

Impedance, Z

8

Chassis diameter

12”

Article No.

SIC-Z007847C

Weight

6.7 kg/db
