Shipping within (if available from supplier)

3-6 weeks

Manufacturer

Sica

Further data

Orderable

Details

General Specifications

Nominal Diameter	321 mm / 12 in
Nominal Impedance	8 Ω
Rated Power AES	450 W
Continuos Program Power	900 W
Sensitivity @ 1W/1m	92.2 dB
Voice Coil Diameter	75 mm (3")
Voice Coil Winding Depth	20 mm
Magnetic Gap Depth	10 mm
Flux Density	1.00 T
Magnet Weight	1790 g
Net Weight	6.7 Kg

Constructive Characteristics

Magnet Type	Ferrite
Basket Material	Aluminium Die-Cast
Voice Coil Winding Material	Copper
Voice Coil Former Material	Fiberglass
Cone Material	Paper
Cone Treatment	Surface Waterproof Treatment
Surround Material	Rubber
Dust Dome Material	Solid Paper

Mounting Information

Overall Diameter	320 mm
Baffle Cutout Diameter	284 mm
Mounting Holes	8 holes 6 on Ø300 mm
Total Depth	140.8 mm

Thiele/Small Parameters

Re	5.2 Ω
Qms	2.96
Qts	0.40
Cms	178 µm/N
Vas	60.9 l
X max	+/- 8.0 mm
N	0.65 %
Fs	37.0 Hz
Qes	0.46
Mms	104.0 g
Bxl	16.57 Tm
Sd	490.9 cm²
X var	+/- 9.0 mm
Le (1KHz)	1.29 mH

Info

Impedance, Z

8

Chassis diameter

12”

Article No.

SIC-Z007942C

Weight

7.3 kg/db
