Shipping within (if available from supplier)

3-6 weeks

Manufacturer

Sica

Further data

Orderable

Details

General Specifications

Nominal Diameter	462 mm / 18 in
Nominal Impedance	8 Ω
Rated Power AES	400 W
Continuos Program Power	800 W
Sensitivity @ 1W/1m	96.9 dB
Voice Coil Diameter	75 mm (3")
Voice Coil Winding Depth	20 mm
Magnetic Gap Depth	10 mm
Flux Density	1.08 T
Magnet Weight	1800 g
Net Weight	8.6 Kg

Constructive Characteristics

Magnet Type	Ferrite
Basket Material	Aluminium Die-Cast
Voice Coil Winding Material	Copper
Cone Material	Paper
Cone Treatment	Humidity Resistant Pulp
Surround Material	Treated Cloth
Dust Dome Material	Solid Paper

Mounting Information

Overall Diameter	462 mm
Baffle Cutout Diameter	417 mm
Mounting Holes	8 holes 6.5×9 on Ø441 mm
Total Depth	196.5 mm

Thiele/Small Parameters

Re	5.1 Ω
Qms	3.05
Qts	0.45
Cms	177 µm/N
Vas	340.0 l
X max	+/- 6.5 mm
N	1.84 %
Fs	30.8 Hz
Qes	0.52
Mms	155.0 g
Bxl	16.90 Tm
Sd	1164.2 cm²
X var	+/- 10.5 mm
Le (1KHz)	1.41 mH

Info

Impedance, Z

8

Chassis diameter

18”

Article No.

SIC-Z008362

Weight

8.6 kg/db
