SICA LP 98.25/245 TW Dome Tweeter
SICA LP 98.25/245 TW Dome Tweeter
29.85 € excl. VAT

SICA LP 98.25/245 TW Dome Tweeter

SICA LP 98.25/245 TW Dome Tweeter
SICA LP 98.25/245 TW Dome Tweeter
SICA LP 98.25/245 TW Dome Tweeter
SICA LP 98.25/245 TW Dome Tweeter
SICA LP 98.25/245 TW Dome Tweeter
SICA LP 98.25/245 TW Dome Tweeter
Manufacturer
Sica
Further data
In stock
29.85 € excl. VAT
Details
General Specifications
TW Nominal Diameter

98 mm
Nominal Impedance

8 Ω
Rated Power AES

25 W
Continuos Program Power

50 W
Rated Noise Power

120 W
Sensitivity @ 1W/1m

93.1 dB
Voice Coil Diameter

25 mm (1")
Voice Coil Winding Depth

1.7 mm
Magnetic Gap Depth

2.0 mm
Flux Density

1.70 T
DC Resistance

6.0 Ω
Resonance Frequency

1.20 KHz
Magnet Weight

245 g
Net Weight

0.6 Kg
Recommended Crossover Frequency

2.5 Khz
Constructive Characteristics
Magnet Type

Ferrite
Voice Coil Winding Material

Copper
Voice Coil Former Material

Aluminium
Ferrofluid in Air Gap

Yes
Diaphragm

Treated Silk
Flange

Aluminium
Spare Part Code

Z009407
Mounting Information
Overall Diameter

98 mm
Baffle Cutout Diameter

78 mm
Mounting Holes

4 holes Ø4.5 on Ø87,5 mm
Total Depth

32.4 mm
Info
Impedance, Z
8
Article No.
SIC-Z009170C
Weight
600 g/db
