2 x In, 3 x Out Digital Signal Processor Extension Board

This interface extension board provides a simple connection solution for customer’s applications. With its headers and a 10 pin cable, the interface extension board can easily be integrated to the DSP Kernal board.

Highlights

• 2 x 2 inches Compact PCB Size
• 2CKT RCA input, 3CKT RCA output
• 1CKT AUX input, 1CKT AUX output
• 1CKT molex Micro-Fit input, 1CKT molex
• Micro-Fit output,
• Powered by DSP kernel board

Product details

Sure Electronics 2 x In, 3 x Out Digital Signal Processor Extension Board

A 10Pin terminal on board is provided to allow the connection with Analog Devices EVAL-ADUSB2Z for programming purposes. This extension board can also be used for more generic connector interfaces. 2 pieces RCA and a 3.5mm AUX jack are provided for input, as well as 3 pieces RCA and a headphone jack for output. Besides that, Molex 4Pin terminals have also been provided on the board for more complex application solutions.
