MB-CM11111 | Small 7-key User-definable | Remote Control

Highlights

• Compact and durable
• Black, ABS packaging
• Powered by two 1.5V AA batteries
• Long service time: 3 years
• Straight transmission distance: 8m
• Available to use keys 100.000 times
• Low power consumption

Product details

Sure Electronics MB-CM11111 | Small 7-key User-definable | Remote Control

Remote control created to help you use the AA-AS32971 amplifier in a much easier way and keep you away from the amp to focus on what you are listening. A voltage-regulated power of high-performance is necessary to provide basic and enough power so that this product could work stably, otherwise any problem caused by poor power is out of the warranty.

Specifications: Dimensions: 110.00 (L) X 45.00 (W) X 18.30 (H) ±0.20 mm • Weight 46 g / 1.6 oz • Power Voltage: DC2.2V- DC3.2V • IC Quiescent Current: > 0.1 mA • IC Low-voltage Detection: 2.4V ± 0.1V (OTP) / 2.4V ± 0.1V (Normal) • Power Consumption (Average): 8-10mA • Power Consumption (Max) 30-50mA • Storage Temperature and Humidity: -10℃ + 60℃, 90％RH (Max) • Operating temperature and humidity: 0℃ + 55℃, 85%RH (Max) • Resonant frequency: 455KHZ ± 1.5KHZ • Carrier wave: 37.9KHZ ± 125KHZ •  Straight Distance: 8.0m • Direction: Up, down, left, right direction, 15° at min. 5.0m distance • Leakage Current: <5uA • Power Supply: DC 2.2V-DC 3.2V • Material of Keys: PET, force: 120-180 g • LED consumed: 35mA ± 0.5mA.
